TGuide S32 Automated Nucleic Acid Extractor

Features

■ The unique magnetic rod vibration mode has large vibration amplitude and high precision.
■ New strong adsorption mode, good magnetic beads adsorption effect and high nucleic acid yield.
■ Limit position protection function, stable and orderly operation of the instrument to avoid failure.
■ Windows Pad and screen button double control mode, powerful program editing function, intuitive, simple and convenient operation.
■ Contamination intelligent control system and UV sterilization module can effectively avoid cross contamination between sample wells and batches.
■ Relying on TIANGEN nucleic acid extraction and purification reagent platform, it provides a comprehensive, complete and high-quality automation solution.

Operating Parameters

Principle

After the sample is lysed by the lysis buffer, the nucleic acid dissociated from the lysis/binding solution is specifically adsorbed by the magnetic beads. Through the cooperation of the magnetic rod and the magnetic tip comb, the magnetic attraction, transfer, release, mixing and other actions are completed to separate the magnetic beads adsorbing the nucleic acid from the lysis/binding solution. Various impurities that are not specifically bound to the magnetic beads are removed in the washing well, and finally the nucleic acid molecules are dissolved in the elution buffer.

Unique Movement Mode of Magnetic Rod

The driving device adopts a stepping motor. With large vibration amplitude of the magnetic rod, the vibration amplitude is automatically adjusted according to the volume of the solution, making sure a good mixing effect. The transmission device adopts a ball screw, with stable operation of magnetic rod, high precision and long service life. All moving parts are equipped with limit position protection function to ensure smooth and orderly operation of the instrument to avoid failures.

New Strong Adsorption Mode

Through a newly designed strong adsorption mode, magnetic beads are adsorbed on the tip of the magnetic rod, so that under the condition of small elution volume, eluent can still cover all magnetic beads. The magnetic beads have good adsorption effect and high nucleic acid yield.

Dual Control Mode of Windows Pad and Screen Buttons

On the basis of the classic button operation, it is remotely controlled with high-performance Windows Pad. The interactive interface of Windows application program is perfectly set, which is more in line with customers’ normal office work and learning Windows usage habits.

Product Guide for TGuide S32
